32G SFP Modules, SFP
Q-logic SFP32-SR-SP-C Compatible 32G Fiber Channel SFP28 850nm 100m DOM LC MMF Transceiver Module
Q-logic SFP32-SR-SP-C Compatible 32G Fibre Channel SFP28 Transceiver Module (MMF, 850nm, 100m, LC, DOM)
The Q-logic SFP32-SR-SP-C compatible module provides 32GBase-SR throughput up to 100m over multimode fiber (MMF) using a wavelength of 850nm via an LC duplex connector. This transceiver is compliant with SFF-8636 standards. Digital diagnostics functions are available via a 2-wire common management interface, as specified in SFF- 8472, to allow access to real-time operating parameters. With these features, this easy-to-install, hot-swappable transceiver is suitable for fiber communications application up to 32G. The FC transceiver is applied to Storage Area Networking in Data Centers, Data Center Fiber Channel Interconnections over Backbone, Enterprise Network SAN Interconnections, etc.
Specifications
Q-logic Compatible | SFP32-SR-SP-C | Vendor Name | Longlife |
Form Factor | SFP28 | Max Data Rate | 28.05Gbps |
Wavelength | 850nm | Max Cable Distance | 100m |
Connector | LC duplex | Optical Components | VCSEL 850nm |
Media | MMF | DOM Support | Yes |
TX Power | -6.7~2dBm | Receiver Sensitivity | <-10.2dBm |
Commercial Temperature Range | 0 to 70°C (32 to 158°F) | Protocols | MSA Compliant |
