D-Link DEM-315GT Compatible 1000BASE-ZX SFP 1550nm 80km DOM Duplex LC SMF Transceiver Module
D-Link DEM-315GT Compatible 1000BASE-ZX SFP Transceiver Module (SMF, 1550nm, 80km, LC, DOM)
D-Link DEM-315GT compatible SFP transceiver supports up to 80km link lengths over LC duplex SMF fiber. Each SFP transceiver module is individually tested to be used on a series of D-Link switches, routers, servers, network interface card (NICs) etc.
Featuring low power consumption, the hot swappable 1G SFP transceiver is ideal for Internet Service Provider (ISP) Gigabit Ethernet communication links, Enterprise LAN & SAN Networks, Data Center LAN & SAN Networks and other optical links.
Specifications
.
Compatible | DEM-315GT | Vendor Name | Longlife |
Form Factor | SFP+ | Max. Data Rate | 10.3125Gbps |
Wavelength | 850nm | Max. Cable Distance | 300m@OM3/400m@OM4 |
Connector | Duplex LC | Media | MMF |
Transmitter Type | VCSEL | Receiver Type | PIN |
TX Power | -7.3~-1dBm | Receiver Sensitivity | < -11.1dBm |
Powerbudget | 3.8dB | Receiver Overload | -1dBm |
Typical Power Consumption | <1W | Extinction Ratio | >3dB |
Commercial Temperature Range | 0 to 70°C (32 to 158°F) | Protocols | IEEE 802.3ae, SFF-8472, SFF-8431, SFF-8432, SFP+ MSA Compliant, CPRI, eCPRI |
