Cisco C17 DWDM-SFP10G-63.86-I Compatible 10G DWDM SFP+ 1563.86nm 40km Industrial DOM Duplex Duplex LC SMF Transceiver Module
Cisco DWDM-SFP10G-63.86-I Compatible 10G DWDM SFP+ Transceiver Module (SMF, 1563.86nm, 40km, LC, Industrial, DOM)
Cisco compatible SFP+ transceiver supports up to 40km link lengths over single-mode fiber (SMF) via an LC duplex connector. This transceiver is compliant with SFF-8431 and SFF-8432 MSA standards. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, to allow access to real-time operating parameters. With these features, this easy to install, hot swappable transceiver is suitable to be deployed in the DWDM networking equipment in metropolitan access and core networks.
Specifications
|
Cisco Compatible
|
DWDM-SFP10G-63.86-I | Vendor Name | Longlife |
|
Form Factor
|
SFP+ |
Max Data Rate
|
10Gbps |
|
Wavelength
|
1563.86nm |
Max Cable Distance
|
40km |
|
Connector
|
Duplex LC |
Optical Components
|
EML DWDM |
|
Media
|
SMF |
DOM Support
|
Yes |
|
TX Power
|
-1~4dBm |
Receiver Sensitivity
|
<-16dBm |
|
Industrial Temperature Range
|
-40 to 85°C (-40 to 185°F) |
Protocols
|
SFP+ MSA Compliant, CPRI, eCPRI |
