Avago AFBR-725SMZ Compatible 25GBASE-SR SFP28 850nm 100m DOM Duplex LC MMF Optical Transceiver Module

Stok kodu: LNF-AFBR-725SMZ







    Avago AFBR-734SMZ Compatible 25GBASE-SR SFP28 Optical Transceiver Module for Data Center and Telecom (MMF, 850nm, 100m, LC, DOM)

    Avago AFBR-734SMZ compatible SFP28 transceiver adopts LC duplex connectors, reaching a link up to 100m over OM4 MMF (70m over OM3). The SFP28 transceiver module supports running on the same 1G/10G network cabling Infrastructure, giving 2.5 times increase in speed at least, and the built-in DDM/DOM functions monitor the real-time operating status. Besides, it offers interoperability, laying a foundation for the next-generation network upgrade. Each SFP28 transceiver module is individually tested on a series of Cisco switches, and is fully compliant with the SFP28 MSA, RoHS, CPRI, and the eCPRI standards. Featuring low power consumption, high speed, this 25G transceiver is ideal for 25G Ethernet, telecom, and data center.

    Specifications
    Avago Compatible
    AFBR-734SMZVendor NameLonglife
    Form Factor
    SFP28
    Max Data Rate
    25.78Gbps
    Wavelength
    850nm
    Max Cable Distance
    100m@OM4/70m@OM3
    Connector
    Duplex LC
    Media
    MMF
    Transmitter Type
    VCSEL
    Receiver Type
    PIN
    TX Power
    -7.9~1.9dBm
    Receiver Sensitivity
    <-6dBm
    Powerbudget
    -1.9dB
    Receiver Overload
    2.4dBm
    Power Consumption
    ≤1W
    Extinction Ratio
    >2dB
    CDR (Clock and Data Recovery)
    TX & RX Built-in CDR
    FEC Function
    Support RS-FEC, FC FEC
    Commercial Temperature Range
    0 to 70°C (32 to 158°F)
    Protocols
    SFF-8472, SFF-8024, SFF-8431, SFF-8432
    DDM/DOM
    Supported
    Warranty
    5 Years
    Core Size
    50/125 µm
    Packaging Technology
    COB Packaging
